Dates Fumigation Chamber

Description

The Dates Fumigation Chamber from SmartMak™ represents a fast solution to obtain completely sterilized fruits, vegetables, herbs or seeds, free from insects and pests, with a thermal gas mechanism.

Dates Fumigation Chamber description:

The Dates Fumigation Chamber is considered one of the Food processing equipment, from SmartMak™ one of the most important Food processing equipment manufacturers.



The Dates Fumigation Chamber from SmartMak™ has been designed with a working mechanism that draws the air completely from inside the chamber, which is characterized by being sealed, and the air is drawn through the attached vacuum pumps, and then the gas used in the sterilization is pumped into the unit from the bottom to the top continuously by pneumatic motors in order to ensure that gas reaches every cubic centimeter inside the unit, the chamber is heated by overhead heaters to aid in the sterilization process.

Usually, a mixture of CO2 gas with ethyl formate is used for sterilization, and cylinders containing a ready mix of the two gases can be used, but we provide you with the possibility of adding a gas mixer as an optional accessory to the room, which enables you to obtain the mixture directly and thus save cost Ready-made cylinders.

The entire system is completely operated by an electronic control unit (PLC) that has been incorporated inside the control panel to set the control process for the time of gas discharge, flow and distribution within the unit.

Technical Information:

  • Machine structure: Low carbon steel (ST 37) supported with NPI-200 profile
  • Electrical Specifications: 3 Phase | 380 V | 50-60 Hz
  • Main Controller: Omron
  • Touch Screen and Control: Omron touch screen control – It controls all operations of the machine, and includes four different languages

Materials:

Interior Parts Manufacturers:
